Installation of panel facades
Here you get an insight into how the open facade systems Woodfac Panel and Alufac Panel are installed. All our facade systems are like building with LEGO. They offer countless creative combinations, are simple to handle, and provide a precise, sharp look without visible screws.
The simple handling and easy plug-and-play installation consist of only three components, which are installed in three steps.
3 steps and 3 components
The three components – aluminum panel, wood or aluminum slat, and mounting screw – are all prepared for thermal movement, providing full control over all phases of the construction.
Watch the video for a quick introduction to installing the panel systems, and click on the image below to read more about the three installation phases.
We strive to create a seamless and efficient process for our customers, while at the same time delivering an exclusive product from design to installed facade.
Installation in 3 steps
The installation of the system usually begins with a starter profile. Alternatively, with a rebate profile if the installation begins at a window or a door. Starter, end, and rebate profiles are available in various widths.
The panel is angled into the previous coupling and generally pulled to the right for maximum coverage width. Then the panel is tilted in a single motion toward the suspension profile – “click.”
Once the panel is in place against the suspension profile, it is fastened with stainless steel mounting screws. The panels are prepared for thermal movement, and the thermal zero point must be positioned consistently on all panels.
WOODFAC Panel
Alufac Panel er et alsidigt panelsystem, der kombinerer æstetik og funktionalitet i en løsning, der kan tilpasses dine specifikke ønsker – uden at begrænse den arkitektoniske frihed.
Det er et lukket facadesystem, på lige fod med Woodfac Panel, men med den væsentlige forskel, at Alufac Panel er lamelbeklædning i aluminium fremfor træ. Alufac Panel er et system med alu-lameller i Greenline aluminium.
ALUFAC PANEL
Alufac Panel is a versatile panel system that combines aesthetics and functionality in a solution that can be adapted to your specific wishes – without limiting architectural freedom. It is a closed facade system, similar to Woodfac Panel, but with the essential difference that Alufac Panel features aluminum slat cladding instead of wood. Alufac Panel is a system with aluminum slats made of Greenline aluminum.
